Blower Motor – Single Shaft 12V CW (1001059)

Description: Navistar Trucks Single Shaft Blower Motor 1669342-C1, HA1135, 421844-C1, 488842-C91, 488832-C1
Volts: 12V
Length: 4.69” (OA Body)
Wire Type: 2 wire harness
Motor Diameter: 3”
Motor Length: 4”
Mount Type: Stud
Rotation: CW
Shaft Length: 1.56”
Shaft Type: Single (5/16” dia)
Speed(s): 1
Mounting Stud Distance: 2.31”
Vent: Vented

Application:
International (Navistar) Blower Motor 4000 Series (1985-1978); 5000 Series (1993-1978)

Cross Reference:1001059, 3341, 203165, 203183, 203249, HA1135, HA1900, HA11250, HA11350, HA20050,937169, 150-4477, 102-1080, 15-8139, 02-47017, E-803031, E-803045, 2807-510-009, 2807-517-005, 2807-517-007, 2807-517-043, 2807-541-010, 2809-541-174, 2809-550-008, 2819-541-010, 2819-541-010N, ZGG11643, ZGG13582, 35541, 35557, A22-21403-AE, 406141, 2807-517-019, 1012002, 1099012, 274339, 1-1643, 1-3297, 1-3582, 208994, 421844-C1, 488832-C1, 488842-C91, 26-13260, 73R0652, PE2525Q, PF2425Q, PF2628Q, RF2652032715, PM341, 30-1003, 3949386, 85100157, 26-13356, 26-14556, A2221403AE, 421844C1, 488832C1, 488842C91, 123754, PTAC3341
